| Engine | ||
| Make | Caterpillar | |
| Model | C7 ACERT | |
| Gross Power | 190 hp | 141.7 kw |
| Net Power | 169 hp | 126 kw |
| Power Measured @ | 1800 rpm | |
| Displacement | 439.4 cu in | 7.2 L |
| Number of Cylinders | 6 | |
| Operational | ||
| Operating Weight | 54660 lb | 24790 kg |
| Fuel Capacity | 137 gal | 520 L |
| Cooling System Fluid Capacity | 7.9 gal | 30 L |
| Hydrauilc System Fluid Capacity | 79 gal | 300 L |
| Engine Oil Capacity | 8 gal | 30 L |
| Swing Drive Fluid Capacity | 2.6 gal | 10 L |
| Alternator Supplied Amperage | 65 amps | |
| Hydraulic System Relief Valve Pressure | 5221 psi | 36000 kPa |
| Hydraulic Pump Flow Capacity | 116.2 gal/min | 440 L/min |
| Swing Mechanism | ||
| Swing Speed | 9.6 rpm | |
| Swing Torque | 54737 lb ft | 73400 Nm |
| Undercarriage | ||
| Number of Shoes per Side | 51 | |
| Shoe Size | 32 in | 800 mm |
| Number of Carrier Rollers per Side | 2 | |
| Number of Track Rollers per Side | 8 | |
| Max Travel Speed | 3.4 mph | 5.4 km/h |
| Drawbar Pull | 51032 lb | 227 kN |
| Track Gauge | 8.5 ft in | 2590 mm |
| Buckets | ||
| Reference Bucket Capacity | 1.8 yd3 | 1.4 m3 |
| Maximum Bucket Capacity | 2.6 yd3 | 2 m3 |
| Boom/Stick Option (HEX) 1 | ||
| Boom/Stick Option (HEX) 1 | Boom 19'4" (5900mm) / Stick 11'10" (3600mm) -Reach | |
| Shipping Height of Unit | 11.3 ft in | 3430 mm |
| Shipping Length of Unit | 33 ft in | 10050 mm |
| Max Digging Depth | 24.1 ft in | 7328 mm |
| Max Reach Along Ground | 34.6 ft in | 10549 mm |
| Max Cutting Height | 32.4 ft in | 9887 mm |
| Max Loading Height | 23.1 ft in | 7043 mm |
| Max Vertical Wall Digging Depth | 21.6 ft in | 6575 mm |
| Boom/Stick Option (HEX) 2 | ||
| Boom/Stick Option (HEX) 2 | Boom 19'4" (5900mm) / Stick 9'8" (2950mm) -Reach | |
| Shipping Height of Unit | 10.4 ft in | 3170 mm |
| Shipping Length of Unit | 33 ft in | 10060 mm |
| Max Digging Depth | 22.5 ft in | 6846 mm |
| Max Reach Along Ground | 32.3 ft in | 9829 mm |
| Max Cutting Height | 32.7 ft in | 9946 mm |
| Max Loading Height | 21.6 ft in | 6590 mm |
| Max Vertical Wall Digging Depth | 19.9 ft in | 6075 mm |
| Boom/Stick Option (HEX) 3 | ||
| Boom/Stick Option (HEX) 3 | Boom 19'4" (5900mm) / Stick 8'2" (2500mm) -Reach | |
| Shipping Height of Unit | 10.8 ft in | 3300 mm |
| Shipping Length of Unit | 33.2 ft in | 10100 mm |
| Max Digging Depth | 21 ft in | 6396 mm |
| Max Reach Along Ground | 30.8 ft in | 9395 mm |
| Max Cutting Height | 32 ft in | 9750 mm |
| Max Loading Height | 21 ft in | 6394 mm |
| Max Vertical Wall Digging Depth | 18.5 ft in | 5633 mm |
| Boom/Stick Option (HEX) 4 | ||
| Boom/Stick Option (HEX) 4 | Boom 17'5" (5300mm) / Stick 8'2" (2500mm) -Reach | |
| Shipping Height of Unit | 11.3 ft in | 3450 mm |
| Shipping Length of Unit | 31.1 ft in | 9480 mm |
| Max Digging Depth | 21.3 ft in | 6488 mm |
| Max Reach Along Ground | 31 ft in | 9446 mm |
| Max Cutting Height | 32.3 ft in | 9849 mm |
| Max Loading Height | 20.7 ft in | 6302 mm |
| Max Vertical Wall Dig Depth | 18.7 ft in | 5694 mm |
| Boom/Stick Option (HEX) 5 | ||
| Boom/Stick Option (HEX) 5 | Boom 33'6" (10200mm) / Stick 25'9" (7850mm) -Reach | |
| Shipping Height of Unit | 10.3 ft in | 3150 mm |
| Shipping Length of Unit | 47.1 ft in | 14340 mm |
| Max Digging Depth | 47.9 ft in | 14594 mm |
| Max Reach Along Ground | 61 ft in | 18603 mm |
| Max Cutting Height | 50.6 ft in | 15411 mm |
| Max Loading Height | 43.6 ft in | 13285 mm |
| Max Vertical Wall Dig Depth | 45.6 ft in | 13922 mm |
| Dimensions | ||
| Width to Outside of Tracks | 11.1 ft in | 3390 mm |
| Height to Top of Cab | 9.8 ft in | 2980 mm |
| Ground Clearance | 1.4 ft in | 440 mm |
| Counterweight Clearance | 3.5 ft in | 1060 mm |
| Tail Swing Radius | 9.8 ft in | 3000 mm |
| Length of Track on Ground | 12.6 ft in | 3830 mm |
