If you need to rent one of the smallest Mini Excavators for a commercial or residential
project that involves close-quarters (through doorways) work, the micro, compact and
powerful MITSUBISHI MS070-8 ini Excavator might be the perfect choice. It’s maximum
digging depth of 5 feet 8 inch and digging reach of 10 feet 1 inch make it a versatile tool.
The next step up from the MITSUBISHI MS070-8 is the John Deere 17D is a John
Deere 17D Mini Excavator Rental
With an overall width of only 2 feet 5 inches) the MITSUBISHI MS070-8 can easily drive through
narrow passages and doors. Both indoor and outdoor jobs are now accessible with the under
1000 kg (2,205 lb) weight making easy trailer transportation between sites possible.
Power: The MITSUBISHI MS070-8 high drawbar pull (pulling force) delivers plenty of
power for backfilling trenches or transporting materials.
Compact: The MITSUBISHI MS070-8 mini excavator’s independent-swing boom and
360-degree rotation allows you to work in areas where shovels used to be the only
option.
Visibility: The MITSUBISHI MS070-8 unobstructed visibility provides you
with increased productivity and safety.
Versatile: With multiple
attachment options, the MITSUBISHI MS070-8 is an extremely flexible tool.
What can you do with a Caterpillar 300 . 9 Mini Excavator rental?
- Dig up sewage pipes or electrical conduit
- Break up concrete with the hammer attachment
- Backfill trenches
- Dig trenches
- Prepare grounds for landscaping
- Remove debris from construction sites
- Fence pole installation
- Help Plant trees
We provide quick delivery on all payloader rentals, mini-excavator rentals, and compact
track loader rentals throughout the Greater Seattle Region.
** equipped excavator rentals will relay error codes, cautions, maintenance
items, fuel levels, and much more.
OPERATIONAL DATA
| Digging force - Bucket |
2000.0
lb |
| Digging force - Stick |
1011.0
lb |
| Operating weight with Safety frame
|
2170.0
lb |
| Operating weight without Safety frame
|
2061.0
lb |
ENGINE
| Engine Model |
Yanmar
31NV70 |
| Net Power |
13.0
hp |
| Rated speed |
2100.0
RPM |
| Battery |
12 V, 20
Amp |
| Diesel tank volume |
2.64
gal |
| Displacement |
52.0
in3 |
| Flywheel output ISO |
13.0
hp |
| Gross Power (ISO 14396) |
18.0
hp |
| Make/type |
Yanmar
31NV70 |
| Maximum engine output |
18.0
hp |
| Type |
Water
cooled model 3-cylinder diesel engine |
WEIGHT
| Operating weight with Safety frame
|
2170.0
lb |
| Operating weight without Safety frame
|
2061.0
lb |
WEIGHTS
| Operating Weight |
2061.0
lb |
DIMENSIONS
| Boom swing angle (Left) |
55.0
Degrees |
| Boom swing angle (Right) |
56.0
Degrees |
| Height with ROPS safety frame folded
down |
4.94
ft |
| Height with ROPS safety frame
unfolded |
7.47
ft |
| Length of undercarriage |
4.0
ft |
| Maximum Digging Depth |
5.68
ft |
| Maximum Dump Height |
6.68
ft |
| Maximum dig height |
9.39
ft |
| Maximum dozer dig depth |
7.0
in |
| Maximum dozer lift height |
8.0
in |
| Maximum reach |
10.09
ft |
| Maximum reach at ground level |
9.92
ft |
| Maximum vertical dig depth |
4.43
ft |
| Minimum front linkage swing radius
|
3.77
ft |
| Tail swing radius |
2.41
ft |
| Track width |
7.0
in |
| Transport length (arm lowered) |
9.0
ft |
| Undercarriage Width - Extended |
2.83
ft |
| Undercarriage Width - Retracted |
2.33
ft |
| Width |
2.4
ft |
HYDRAULIC SYSTEM
| Pumps |
2 gear
pumps |
| Discharge capacity |
11.4 + 11.4
L/min (3 + 3 gal/min) |
| Hydraulic tank capacity |
3.7
gal |
| Operating pressure for the work and
travel hydraulics |
2466.0
psi |
| Operating pressure pivot |
1015.0
psi |
CHASSIS AND SWIVEL GEAR
| Gradeability |
30°/58% |
| Ground clearance |
5.0
in |
| Ground pressure |
3.5
psi |
| Machine swing speed |
8.0
RPM |
| Number of rollers per side |
2
|
| Track width |
7.0
in |
| Travel speed |
1.12
mph |
OPERATING SPECIFICATIONS
| Machine Overhang |
12.5
in |
| Stick Length - Standard |
34.8
in |
DOZER BLADE
| Dig depth |
7.0
in |
| Height |
8.0
in |
| Lift height |
8.0
in |
| Width |
28.0
in |
NOISE EMISSIONS
| Sound power level (LWA) (to
2000/14/EG) |
93.0
dB(A) |
