Need to rent a payloader for a commercial or residential project that can carry more weight than the John Deere 313D payloader? Then the compact and powerful John Deere 315D Skid Steer rental might be your perfect choice.
Powerful: The 315D payloader’s Turbocharged 2.4L diesel engine delivers 45 HP (same power as the John Deere 313D payloader rental), but allows you to carry loads of up to 1500 lbs (vs. 1260lbs. for the 313D). In addition, the 315D’s Tipping Load is 3000 lbs. vs. 2,525 lbs. for the 313D.
Compact: At 59 inches wide (same as the 313D), the 315D manoeuvres confined areas and tight spots with ease. As with the 313D, the 315D’s superior visibility gives you a clear view of the bucket and the tire edges. (Helpful in close quarters).
Superior bucket angle: As with the 313D, the 315D’s 40-degree dump angle allows the bucket to empty all content (including sticky material).
Comfort: As with the 313D, the John Deere 315D payloader’s sculptured high back seat will help you keep productivity high.
Reliability: When you rent a payloader like the John Deere 315D you don’t have to worry about performance and reliability. As an example, the 315D’s heavy‐duty drive chains never need adjusting and the battery is maintenance free.
We provide quick delivery on heavy equipment rentals throughout the Seattle region. See our Delivery rates for more details.
KOMTRAX equipped excavator rentals will relay error codes, cautions, maintenance items, fuel levels, and much more.
|A. Length with Bucket||10.7 ft in||3270 mm|
|B. Width Over Tires||4.9 ft in||1500 mm|
|C. Height to Top of Cab||6.4 ft in||1960 mm|
|D. Wheelbase||3.4 ft in||1040 mm|
|E. Ground Clearance||7.6 in||193 mm|
|F. Length w/o Bucket||8.4 ft in||2570 mm|
|G. Clearance at Max Lift and Dump||7.4 ft in||2260 mm|
|H. Reach at Max Lift and Dump||15.8 in||401 mm|
|Gross Power||49 hp||36.5 kw|
|Net Power||45 hp||33.6 kw|
|Power Measured @||2400 rpm|
|Displacement||149 cu in||2.4 L|
|Number of Cylinders||4|
|Operational Weight||5200 lb||2358.7 kg|
|Fuel Capacity||17.4 gal||66 L|
|Cooling System Fluid Capacity||1.6 gal||6.2 L|
|Engine Oil Fluid Capacity||2.4 gal||9 L|
|Hydraulic System Fluid Capacity||5 gal||19 L|
|Chain Box Fluid Capacity - each side||4.3 gal||16.3 L|
|Max Speed||6.8 mph||10.9 km/h|
|Tire Size||10x16.5 8 PR|
|Operating Voltage||12 V|
|Alternator Supplied Amperage||70 amps|
|Operating Load Rating||1501.3 lb||681 kg|
|Tipping Load||3000 lb||1360.8 kg|
|Breakout Force||3302.5 lb||1498 kg|
|Bucket Capacity||0.59 yd3||0.45 m3|
|Pump Flow Capacity||16.1 gal/min||61 L/min|
|Relief Valve Pressure||3450 psi||23786.9 kPa|
|Length with Bucket||10.7 ft in||3270 mm|
|Length w/o Bucket||8.4 ft in||2570 mm|
|Width Over Tires||4.9 ft in||1500 mm|
|Height to Top of Cab||6.4 ft in||1960 mm|
|Clearance at Max Lift and Dump||7.4 ft in||2260 mm|
|Wheelbase||3.4 ft in||1040 mm|
|Ground Clearance||7.6 in||193 mm|
|Reach at Max Lift and Dump||15.8 in||401 mm|
|Turning Radius from Center - inc bucket||76 in||1930 mm|
